Aten PE6216 [38/76] Connections

eco PDU Series User Manual

Outlet Access

Connections

When you log in to the eco PDU, the interface opens with its default selection

of the Outlet Access tab; and the Connections menu. The contents of the PDU

Status and Outlet Status sections are displayed in the main panel.

Note: Only enabled eco PDU models will display the Outlet Status submenu

section. Other models provide only PDU Status monitoring.

See Comparison Chart, page 3, for which models support PDU and

Outlet Status or PDU Status only monitoring.
