Adjustable footplate footplate F tilts in order to keep as much of its surface in contact with the workpiece adjust footpl ate by hoi ding the saw firmly and turn ng footplate to desired position Blade storage compartment ensure that storage compartment G is closed to prevent blades from falling out Operating the tool I securely clamp the workpiece mark the cutting line on the workpiece select desired sawing speed with wheel C connect plug to power source light B turns on indicating that the tool is receiving power hold the tool wi th one hand on handle H and th e other on the insulated barrel grip J switch on the tool the tool should run at full speed before the blade enters the workpiece guide the tool along the marked cutting line keep footplate F firmly against the workpiece to minimize counter force and vibration Holding and guiding the tool I while working always hold the tool at the grey coloured grip area s keep ventilation slots K uncovered do not apply too much pressure on the tool let the tool do the work for you I ensure that the saw blade extends beyond the work throughout the stroke Adjusting effective stroke length use both adjustment screws Lfor sliding footplate F forward backwards in order to enlarge reduce the effective stroke length I do not attempt to adjust the effective stroke length with screw M which Is pre set at manufacturing If the tool should fail despite the care taken in manufacturing and testing procedures repair should be carried outby an after sales service centre for SKIL power tools send the tool undismantled together with proof of purchase to your dealer or the nearest SKIL service station addresses as well as the service diagram of the tool are listed on www skilmasters com ENVIRONMENT Do not dispose of electric tools accessories and packaging together with household waste material only for EU countries in observance of European Directive 2012 19 EC on waste of electric and electronic equipment and its implementation in accordance with national law electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility symbol will remind you of this when the need for disposing occurs DECLARATION OF CONFORMITY C We declare under our sole responsibility that this product is in conformity with the following standards or standardized documents EN 60745 EN 61000 EN 55014 in accordance with the provisions of the directives 2004 108 EC 2006 42 EC 2011 65 EU Technical file at SKIL Europe BV PT SEU ENG1 4825 BD Breda NL Marijn van der Hoofden Operations Engineering Olaf Dijkgraaf Approval Manager APPLICATION ADVICE SKIL Europe BV 4825 BD Breda NL Plunge cutting Plunge cuts can be made in wood and other soft materials without pre drilling a hole use a thick saw blade mount the blade with the teeth facing upward hold the saw upside down as illustrated mark desired cutting line on the workpiece select position 1 2 or 3 with wheel C tilt the tool so that the blade does not touch the workpiece switch on the tool and carefully engage the moving saw blade into the workpiece after the blade has penetrated through the workpiece continue sawing along the marked cutting line I do not make plunge cuts In metal materials When cutting metals lubricate saw blade regularly with oil 04 12 2013 NOISE VIBRATION Measured in accordance with EN 60745 the sound pressure level of this tool is 89 dB A and the sound power level 100 dB A standard deviation 3 dB and the vibration hand arm method uncertainty K 1 5 m s2 when cutting chipboard 10 1 m s2 when cutting wooden beams 9 2 m s2 The vibration emission level has been measured in accordance with a standardised test given in EN 60745 it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned using the tool for different applications or with different or poorly maintained accessories may significantly increase the exposure level the times when the tool is switched off or when it is running but not actually doing the job may significantly reduce the exposure level I protect yourself against the effects of vibration by maintaining the tool and its accessories keeping your hands warm and organizing your work patterns MAINTENANCE SERVICE Always keep tool and cord clean especially ventilation slots K I disconnect the plug before cleaning 9
