Cleaning the lawn tractor
464865_a 41
Do not use a high-pressure cleaner for cleaning.
The water jet from a high-pressure cleaner or a
garden hose can damage the electrical system or
bearings.
In particular, make sure that no water comes into
contact with the engine, transmission and deflec-
tion pulleys, as well as the entire electrical system.
WARNING!
Dangers when cleaning!
During all cleaning work:
Switch off the engine and remove
the ignition key.
Remove the spark plug connector.
Protective devices removed for
cleaning must be reinstalled after-
wards.
DANGER OF BURNS: Do not clean
the lawn tractor until it has cooled
down. The engine, transmission and
silencer get very hot!
DANGER OF LACERATIONS:
When working on the cutters, pay at-
tention to the sharp blades. In mo-
wers with more than one blade, mo-
ving one cutter can cause the other
to move as well!
Cleaning the grass catcher
To do this, remove the grass catcher and clean it
by spraying inside and out with water from a hose.
Firmly adhering contamination must be scraped
off carefully, such as by using a brush. Especially
in grass catchers with a fabric covering, take care
not to damage the fabric.
ADVICE
Empty the grass catcher before cleaning
as Rasentraktor reinigen described. A
full grass catcher is too heavy to be re-
moved safely.
Removing a grass catcher
1. Switch off the engine.
2. Tilt the grass catcher slightly.
3. Remove the grass catcher upwards.
Removing an electrically operated grass
catcher
1. Switch off the engine.
2. Make sure that the electrically operated grass
catcher is closed.
3. Tilt the grass catcher (approx. 30°).
4. Remove the grass catcher upwards.
Cleaning the deck, engine and transmission
Do not use water or a high-pressure cleaner to
spray down the engine or any of the bearing points
(wheels, transmission, blade bearing).
Water penetrating the ignition system, carburettor
and air filter can cause malfunctions. Water in the
bearing points can lead to loss of lubrication, and
thus cause irreparable damage to the bearings.
Use a cloth, hand brush, long-handled paintbrush
or similar for removing dirt and grass residues.
CAUTION!
Damage to the electrical system by
penetrating water!
Take care when cleaning the tractor with
water to ensure that no water gets into
the electrical system!
Cleaning the discharge channel
Regular cleaning ensures that the cutting height
adjustment can be moved easily.
The discharge channel consists of two parts pus-
hed one inside the other. The lower part is firmly
engaged in the lower deck. The upper part can be
pulled out for cleaning.
1. Remove the grass catcher.
2. Remove the screws (17a) on the left and right
of the discharge channel.
3. Pull the discharge channel through the back
wall and out to the rear.
4. Thoroughly clean the upper and lower disch-
arge channel.
5. Insert the discharge channel into the back
wall. When doing this, make sure that the up-
per and lower parts fit neatly one inside the
other.
6. Screw it on tight using the two fastening
screws.
7. The grass catcher can be reinstalled.
Cleaning the mowing system
There are connections for a half-inch water hose
coupling (18a) on the mower deck. The mowing
system can be cleaned by connecting a water
hose.
The grass catcher or a suitable accessory such as
a deflector must be installed during the cleaning
process.
1. Connect the water hose to the lawn tractor
(18a) and turn on the water.
2. Start the engine and set it to a medium engine
speed.
