Al-Ko Powerline T 23-125.4 HD V2 [42/96] Maintenance schedule
![Al-Ko Powerline T 23-125.4 HD V2 [42/96] Maintenance schedule](/views2/1098205/page42/bg2a.png)
en
Maintenance
42 464865_a
3. Lower the mower mechanism to the lowest
cutting height.
4. Switch on the mower mechanism.
5. The mowing system will be cleaned within a
few minutes.
6. Switch off the mower mechanism.
7. Switch off the engine.
8. Turn off the water and disconnect the hose.
9. Start the engine again and allow the mower
mechanism to run for a few more minutes in
order to fling out the water.
10. Clean the grass catcher.
MAINTENANCE
WARNING!
Dangers during maintenance!
During all maintenance work:
Switch off the engine and remove the ignition key.
Remove the spark plug connector.
Protective devices removed for maintenance must be reinstalled afterwards.
DANGER OF BURNS: Do not work on the lawn tractor until it has cooled down. The engine,
transmission and silencer get very hot!
DANGER OF LACERATIONS: When working on the cutters, pay attention to the sharp
blades. In mowers with more than one blade, moving one cutter can cause the other to
move as well.
Parts are only allowed to be renewed by genuine spare parts.
If in doubt, always visit a specialist workshop or contact the manufacturer.
Maintenance schedule
The following jobs are allowed to be carried out by the user independently. All other maintenance, service
and repair work must be carried out in an authorised service workshop.
In addition, please also comply with the recommended annual lubrication tasks as indicated in the lub-
rication plan.
Activity Before
each use
After
each use
After the
first 5
hours
Every 25
operating
hours
Every 50
operating
hours
Each
time
before
putting
into
storage
Checking the engine oil le-
vel
)*
X
Changing the engine oil
)*
X X
Cleaning the air filter
)*
X
Renewing the air filter
)*
X
Checking the spark plug
)*
X
Checking the brake (test
braking on a straight path)
X
Checking the tyre pressure
(Reifendruck prüfen)
X
