Al-Ko Powerline T 23-125.4 HD V2 [44/96] Starter battery
![Al-Ko Powerline T 23-125.4 HD V2 [44/96] Starter battery](/views2/1098205/page44/bg2c.png)
en
Maintenance
44 464865_a
5. Secure the lawn tractor by placing a sturdy
support (e.g. wooden block) under a sup-
porting part of the chassis so that it cannot
drop down even if the jack were to slip or tip
over.
6. Pull off the protective cap (19a).
7. Use a screwdriver to press out the lock was-
her (19b). Make sure not to lose the parts.
8. Pull off the washer (19c).
9. Pull the wheel off the axle.
ADVICE
Do not lose the feather key when pulling
the rear wheels off the axle!
10. Clean the axle and the hole in the wheel be-
fore reassembly, and grease both of them
with multi-purpose grease.
11. Put the wheel onto the axle.
ADVICE
When pushing on the rear wheels, make
sure that the grooves for the feather key
and the rear wheel are aligned so that
the feather key can be pushed in without
needing undue force.
12. Put the washer onto the axle.
13. Push the lock washer into the groove on the
axle. If you use a pair of pliers to do this, take
care not to damage the axle using the pliers.
14. Put the protective cap onto the axle.
15. Remove the securing support and use the
jack to lower the tractor carefully down to the
ground.
Starter battery
No charger is supplied for the starter battery of the
lawn tractor.
Precise battery designation: see battery box. The
starter battery is located under the engine cover.
The starter battery is always supplied from the
factory pre-charged.
WARNING!
Danger if the starter battery is not
handled correctly!
Please comply with the following points
to avoid dangers from incorrect handling
of the battery!
Do not store the starter battery in the imme-
diate vicinity of naked flames, do not burn it
or place it on heaters. Risk of explosion.
Keep the starter battery in a cool, dry room
(10 - 15 °C) over winter. Avoid storing at tem-
peratures below the freezing point.
Do not leave the starter battery without
charge for a long period. If the starter battery
is not used for a long period, it should be char-
ged using a suitable charger.
Do not smash the starter battery. The electro-
lyte (sulphuric acid) causes chemical burns
to the skin and clothing - immediately rinse
away with plenty of water.
Keep the starter battery clean. Only wipe
clean with a dry cloth. Do not use water, pe-
trol, thinners or the like for this purpose!
Keep the connection terminals clean and
grease them with terminal grease.
Do not short-circuit the connection terminals.
Charging the starter battery
Charging is required:
Before putting into storage before the winter
break.
If the machine will not be used for a long time
(longer than 3 months).
WARNING!
Danger if the starter battery is not
charged correctly!
The charging current of the charger must
not exceed 5 A, and the charging voltage
can be max. 14.4 V. Risk of explosion of
the starter battery if the charging current
is more powerful!
Always remove the ignition key before
starting work on the battery.
We recommend charging this maintenance-free,
gas-tight starter battery using a specially suitable
charger (which can be obtained through retail out-
lets).
Comply with the operating instructions of the char-
ger manufacturer before and during charging of
the starter battery.
1. Remove the ignition key (1d).
2. Open the engine cover.
CAUTION!
Danger of short circuit!
To avoid a short circuit, always dis-
connect the negative cable (-) of the
battery first, and reconnect it last!
Always remove the ignition key be-
fore starting work on the battery!
3. Connect the charger terminals to the connec-
tion terminals of the battery.
