Tesla TT34EXC1-1232IA [35/64] Safety rules and prohibitions
![Tesla TT34EXC1-1232IA [35/64] Safety rules and prohibitions](/views2/1993321/page35/bg23.png)
35
ENG
• Always use the appliance with the air filter mounted . The use of the conditioner without air filter could cause an
excessive accumulation of dust or waste on the inner parts of the device with possible subsequent failures.
• The user is responsible for having the appliance installed by a qualified technician , who must check that it is
earthed in accordance with current legislation and insert a thermomagnetic circuit breaker.
• The batteries in remote controller must be recycled or disposed of properly. Disposal of Scrap Batteries ---
Please discard the batteries as sorted municipal waste at the accessible collection point.
• Never remain directly exposed to the flow of cold air for a long time. The direct and prolonged exposition
to cold air could be dangerous for your health .Particular care should be taken in the rooms where there are
children , old or sick people.
• If the appliance gives off smoke or there is a smell of burning, immediately cut off the pow er supply and contact
the Service Centre.
• The prolonged use of the device in such conditions could cause fire or electrocution.
• Have repairs carried out only by an authorised Service Centre of the manufacturer . Incorrect repair could
expose the user to the risk of electric shock, etc.
• Unhook the automatic switch if you foresee not to use the device for a long time. The airflow direction must be
properly adjusted.
• The flaps must be directed downwards in the heating mode and upwards in the cooling mode.
• Only use the air conditioner as instructed in this booklet. These instructions are not intended to cover every
possible condition and situation. As with any electrical household appliance, common sense and caution are
therefore always recommended for installation , operation and maintenance.
• Ensure that the appliance is disconnected from the power supply when it will remain inoperative for a long
period and before carrying out any cleaning or maintenance.
• Selecting the most suitable temperature can prevent damage to the appliance.
• Do not bend, tug or compress the power cord since this could damage it. Electrical shocks or fire are probably
due to a damaged power cord. Specialized technical personnel only must replace a damaged power cord.
• Do not use extensions or gang modules.
• Do not touch the appliance when barefoot or parts of the body are wet or damp.
• Do not obstruct the air inlet or outlet of the indoor or the outdoor unit. The obstruction of these openings
causes a reduction in the operative efficiency of the conditioner with possible consequent failures or damages.
• In no way alter the characteristics of the appliance.
• Do not install the appliance in environments where the air could contain gas , oil or sulphur or near sources of
heat.
• This appliance is not intended for use by persons (including children ) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Do not climb onto or place any heavy or hot objects on top of the appliance.
• Do not leave windows or doors open for long when the air conditioner is operating.
• Do not direct the airflow onto plants or animals.
• A long direct exposition to the flow of cold air of the conditioner could have negative effects on plants and
animals.
• Do not put the conditioner in contact with water. The electrical insulation could be damaged and thus causing
electrocution.
• Do not climb onto or place any objects on the outdoor unit
• Never insert a stick or similar object into the appliance. It could cause injury.
• Children should be supervised to ensure that they do not play with the appliance. If the supply cord is damaged,
it must be replaced by the manufacturer,its service agent or similarly qualified persons in order to avoid a
hazard.
SAFETY RULES AND PROHIBITIONS
