Tesla TT34EXC1-1232IA [38/64] Remote controller

ENG

REMOTE CONTROLLER

No. Button Function

To turn on or off the air conditioner .

2 OPTION To activate or deactivate optional function (Check below table).

To decrease temperature, time setting or choose the function.

To increase temperature , time setting or choose the function.

5 ECO

To activate / deactivate the ECO function which enables the unit automatically to sets the

operation to achieve energy savings.

6 TURBO

Press this button to activate/deactivate the Superfunction which enables the unit to reach

the preset temperature in the shortest time.

7 MODE To select the mode of operation (AUTO COOL DRY FAN HEAT)

8 FAN

To select the fan speed of auto/mute/low/mid/mid/high/high/turbo , cycle as below

Flashing

1. If press time interval is over 2 seconds, to activate the swing of vertical ﬂap(left/right)

or deactivate it.

2. If press time interval is in 2 seconds, the swing angle range of vertical ﬂap will cycle as

below.

deactivate

1. If press time interval is over 2 seconds, to activate the swing of horizontal

deﬂectors(left/right) or deactivate it.

2. If press time interval is in 2 seconds, the swing angle range of horizontal

deﬂectors(left/right) will cycle as below.

deactivate

Flashing

ON/OFF Mode OPTIONS

AUTO TIMER DISPLAY HEALTH I FEEL

COOL

TIMER DISPLAY HEALTH SLEEP MILDEW I FEEL

DRY TIMER DISPLAY HEALTH MILDEW I FEEL

FAN TIMER DISPLAY HEALTH I FEEL

HEAT

TIMER DISPLAY HEALTH SLEEP I FEEL 8°C H

OFF

AUTO CLEAN TIMER DISPLAY HEALTH I FELL

COOL

CLEAN TIMER DISPLAY HEALTH SLEEP MILDEW I FEEL

DRY CLEAN TIMER DISPLAY HEALTH MILDEW I FEEL

FAN CLEAN TIMER DISPLAY HEALTH I FEEL

HEAT

CLEAN TIMER DISPLAY HEALTH SLEEP I FEEL 8°C H
