Aqua Mini Full DC Inverter Unitary Chiller 50Hz
25
MGRH16A-PA3Z
Cooling
Chilled
water
outlet
temp.
Ambient temp.(℃)
21.00 25.00 30.00 35.00 40.00 46.00
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
(℃)
kW kW W/W kW kW
W/
W
kW kW W/W kW kW W/W kW kW W/W kW kW W/W
5.00 16.23 3.99 4.07 15.29 4.11 3.72 14.42 4.24 3.40 13.63 4.37 3.12 12.77 4.59 2.78 11.75 4.82 2.44
6.00 16.78 4.05 4.14 15.79 4.18 3.78 14.88 4.31 3.46 14.05 4.44 3.16 13.18 4.66 2.83 12.14 4.89 2.48
7.00 17.37 4.13 4.20 16.32 4.26 3.83 15.37 4.39 3.50 14.50 4.53 3.20 13.62 4.76 2.86 12.55 4.99 2.51
8.00 17.90 4.26 4.20 16.81 4.39 3.83 15.82 4.53 3.49 14.91 4.67 3.19 14.01 4.90 2.86 12.93 5.14 2.51
9.00 18.41 4.30 4.28 17.27 4.43 3.90 16.23 4.57 3.55 15.28 4.71 3.24 14.38 4.95 2.91 13.29 5.19 2.56
10.00 19.11 4.36 4.38 17.91 4.50 3.98 16.81 4.64 3.63 15.82 4.78 3.31 14.90 5.02 2.97 13.78 5.27 2.61
11.00 19.64 4.41 4.46 18.39 4.54 4.05 17.25 4.68 3.68 16.21 4.83 3.36 15.29 5.07 3.02 14.16 5.32 2.66
12.00 20.09 4.47 4.49 18.79 4.61 4.08 17.61 4.75 3.71 16.54 4.90 3.38 15.61 5.14 3.03 14.47 5.40 2.68
13.00 20.45 4.51 4.54 19.11 4.65 4.11 17.89 4.79 3.74 16.79 4.94 3.40 15.86 5.19 3.06 14.72 5.45 2.70
14.00 20.96 4.54 4.62 19.57 4.68 4.18 18.30 4.82 3.79 17.15 4.97 3.45 16.23 5.22 3.11 15.08 5.48 2.75
15.00 21.23 4.56 4.65 19.80 4.70 4.21 18.50 4.85 3.82 17.33 5.00 3.47 16.41 5.25 3.13 15.26 5.51 2.77
16.00 21.75 4.61 4.72 20.27 4.75 4.27 18.93 4.90 3.87 17.71 5.05 3.51 16.79 5.30 3.17 15.63 5.57 2.81
17.00 22.03 4.63 4.76 20.51 4.77 4.30 19.14 4.92 3.89 17.88 5.07 3.53 16.97 5.33 3.19 15.82 5.59 2.83
Note: The inlet/outlet water temperature difference is 5°C.
Heating
Note: The inlet/outlet water temperature difference is 5°C.
Hot
water
outlet
temp.
Ambient temp.(℃)
-10 -6 -2 2 7 10 13
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
(℃)
kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W
40.00 9.93 3.03 3.27 12.41 3.45 3.60 14.60 3.83 3.81 16.22 4.16 3.89 17.63 4.38 4.02 19.74 4.65 4.25 22.71 5.02 4.52
41.00 9.61 3.10 3.10 12.03 3.52 3.42 14.17 3.91 3.62 15.76 4.25 3.71 17.15 4.47 3.83 19.17 4.74 4.04 22.01 5.12 4.30
42.00 9.33 3.16 2.95 11.70 3.59 3.26 13.79 3.99 3.46 15.36 4.34 3.54 16.73 4.56 3.67 18.67 4.84 3.86 21.40 5.23 4.09
43.00 9.11 3.22 2.82 11.43 3.66 3.12 13.49 4.07 3.31 15.04 4.43 3.40 16.40 4.66 3.52 18.27 4.94 3.70 20.90 5.33 3.92
44.00 8.93 3.29 2.71 11.22 3.74 3.00 13.26 4.15 3.19 14.80 4.52 3.28 16.16 4.75 3.40 17.97 5.04 3.57 20.52 5.44 3.77
45.00 8.80 3.36 2.62 11.07 3.82 2.90 13.10 4.24 3.09 14.64 4.61 3.18 16.00 4.85 3.30 17.76 5.14 3.45 20.25 5.55 3.65
46.00 8.63 3.39 2.55 10.87 3.85 2.82 12.88 4.28 3.01 14.40 4.65 3.10 15.76 4.90 3.22 17.46 5.19 3.36 19.87 5.61 3.54
47.00 8.37 3.46 2.42 10.56 3.93 2.69 12.53 4.37 2.87 14.03 4.75 2.96 15.37 5.00 3.08 16.99 5.30 3.21 19.31 5.72 3.38
48.00 8.04 3.56 2.26 10.16 4.05 2.51 12.06 4.50 2.68 13.52 4.89 2.77 14.83 5.15 2.88 16.37 5.46 3.00 18.56 5.89 3.15
49.00 7.61 3.70 2.05 9.62 4.21 2.28 11.43 4.68 2.44 12.83 5.08 2.52 14.09 5.35 2.63 15.52 5.67 2.74 17.57 6.13 2.87
50.00 7.12 3.89 1.83 9.01 4.42 2.04 10.72 4.91 2.18 12.05 5.34 2.26 13.24 5.62 2.36 14.57 5.96 2.45 16.46 6.43 2.56
