Aqua Mini Full DC Inverter Unitary Chiller 50Hz
68
Check content when wired controller setting is 1:
(The checki
ng content is the same as the PCB’s checking.)
Order Contents
1 Running mode: 0-shutdown,1-Pump mode,2-Cooling,3-Heating,4-Forced cooling, 5-Forced heating.
2 Fan speed:0-Shutdown,1~7-Fan speed.
3 Total capacity requirements.
4 The revised capacity requirements.
5 Cooling/heating temp. setting.
6 T3 temperature value
7 T4 temperature value
8 Tp temperature Value
9 Tin temp. Value (Inlet water temperature)
10 Tout temp. Value (Outlet water temperature)
11 Tb1 temp. Value (Temperature 1 of heat plate)
12 Tb2 temp. Value (Temperature 2 of heat plate)
13
T6 temp. Value（Reserved ）
14 Outdoor unit current
15 Power supply voltage AD value
16 Electronic expansion valve opening steps
17 The unit model:10-10kW,12-12kW,14-14kW,16-16kW
18 The program version number
19 The last error cord
20 The second error cord
21 The first error cord
22 ---
