Aqua Mini Full DC Inverter Unitary Chiller 50Hz
91
P8: Typhoon protection
CH malfunction: Protection when temperature difference between inlet & outlet water in heating
mode is too large for 5/7kW
CL malfunction: Protection when temperature difference between inlet & outlet water in cooling
mode is too large for 5/7kW.
CP malfunction: Anti-freeze protection of plate heat exchanger for 5/7kW.
PH malfunction: Protection when water temperature in heating mode is too high for 5/7kW.
CH malfunction: Protection when water temperature in heating mode is too high for 10-16kW.
PH malfunction: Protection when temperature difference between inlet water & outlet water is too
large for 10-16kW.
LED dis
p
la
y
s P8
Typhoon protection
YES
Stop the unit to prevent strong wind
to blow the outdoor fan.
Check if strong wind blows outdoor unit or two
outdoor units blows each other.
NO
Check whether the fan motor is damaged.
YES
Replace outdoor fan motor.
NO
Replace the outdoor main PCB
LED displays CH/CL/CP/PH
① Protection when temperature difference between inlet & outlet water in heating/cooling mode is too large；
② Anti-freeze protection of plate heat exchanger③Protection when water temperature in heating mode is too high
Whether actual measured temperature difference between outdoor outlet water
temperature minus inlet water temperature is higher than 14°C
NO
Check inlet water sensor and outlet water sensor is
fall off or damaged.
YES
Replace main PCB.
Place temperature sensor to the related position or replace it.
Check whether the volume of water flow is
enough or not.
Whether water system is stuck.
YES
YES
YES
Replace water system component.
NO
Whether gear of water pump
is chosen right.
NO
Adjust to high
level
YES
Water flow pump head of external water pump choices
Select the proper water pump again.
