Aqua Mini Full DC Inverter Unitary Chiller 50Hz
89
P5: Condenser high temperature protection
When condenser temperature is higher than 62 degrees, the unit will stop operating. When pipe temperature outside is
lower than 52 degrees, the unit will resume operate.
LED displays P5
Condenser high temperature protection
Check whether condenser temperature is higher than 62
degrees
NO
Check whether the resistance of condenser
temperature sensor is correct.
YES
Replace the outdoor main PCB.
NO
Replace the temperature sensor
YES
Whether outdoor temperature is too high(higher than 48
degrees)or not.
NO
Whether heat exchanger needs cleaning.
NO
Check if the EXV is blocked or not.
Clean heat exchan
g
e
r
YES
YES
Replace EXV and then use high pressure
nitrogen to blow the pipe. Vacuumed the
pipe then add the refrigerant again.
YES
Stop the unit
NO
Replace outdoor main PCB.
