107

CHAPTER

7 Front Panel Presets

OVERVIEW

This chapter describes your MOTU Express interface’s

eight factory presets and explains how to:

■ Select a factory preset or one of eight user presets from

the front panel

■ Create your own user presets

■ Use the Presets window in ClockWorks

■ Select presets using patch changes from any MIDI

source (such as a keyboard controller or sequencer)

Factory versus user presets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Selecting a preset on an Express XT . . . . . . . . . . . . . . . . . . . . . . . . . 107

Selecting a preset on a micro express . . . . . . . . . . . . . . . . . . . . . . . 108

Factory Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

User Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

FACTORY VERSUS USER PRESETS

Your Express interface provides eight factory presets and

eight more user presets. Factory presets are “hard-wired”

and cannot be permanently changed. If a factory preset is

the current preset, changes you make to your Express

interface’s settings will not be remembered unless you save

them to one of its eight user presets.

The eight user presets can be conﬁgured any way you wish,

and they can be stored in the interface hardware itself for

later recall.

SELECTING A PRESET ON AN EXPRESS XT

To select a preset from the front panel:

1 If you have a MIDI Express XT, press the BANK button

as needed to choose either the factory preset bank or user

preset bank. The Factory Preset or User Preset LED will

become lit.

2 Repeatedly press the SELECT button until the LED

below the program you want lights up.
