CLOCKWORKS FOR MAC OS 9

100

Setting up the foot switch output data

If you choose “Foot Switch” from the “Pedal type” pop-up

menu, the window displays the data for the foot switch as

shown in Figure 6-44 on page 97.

The data sequence list lets you build a series of MIDI data

events. Here is a summary of what you can do:

To do this Do this

To add a MIDI event that you want

sent when you press the pedal down

(on)

Press on the arrow on the left-hand

side of the Pedal On column.

To add a MIDI event that you want

sent when you release the pedal

(off)

Press on the arrow on the left-hand

side of the Pedal Off column.

To add another MIDI event to

either column

Press on the arrow on the left-hand

side at the bottom of the list.

To edit the settings of an event Double-click the setting you wish to

change.

To add a new event that will be

grouped with the event above it

Press on a arrow anywhere in the

group where the event should be

inserted. The event is inserted

where the arrow points.

To delete an event Click the event to select it and press

the delete key.

To delete an entire row or group Click the square icon to the left of

the row to select it and press the

delete key.

To add a “panic” hit Press on a triangle and choose the

PANIC item.
