MOTU Micro Lite [145/166] Locking a motu interface to smpte

APPENDIX B: SMPTE SYNCHRONIZATION BASICS

145

LOCKING A MOTU INTERFACE TO SMPTE

In order to sync your MIDI device to tape, you must ﬁrst

successfully lock your MOTU Express interface to the

SMPTE on the tape. To do so, you need to:

1. Stripe a tape with SMPTE

2. Connect the MOTU Express interface to the tape deck

3. Prepare the MOTU Express interface to convert SMPTE

4. Roll the tape to see if successful SMPTE lockup has been

achieved

These steps are discussed in chapter 8, “Synchronization”

(page 113). Once lockup has been achieved, you can stop

the tape, set up your MIDI hardware or software, and then

slave it to your MOTU Express interface.
