MOTU Micro Lite [96/166] Modifying a preset

CLOCKWORKS FOR MAC OS 9

MODIFYING A PRESET

You can change any settings of the currently selected

preset in any window in ClockWorks. For example, you

could add or delete a connection in the Device Settings &

Routing window, change a setting in the SMPTE Controls

window, or mute something in the Event Muting window.

If a user preset is selected at the time you make the

modiﬁcation, the change is automatically saved with the

preset. (Saving occurs when you switch to a different

preset or when you quit ClockWorks.)

If a factory preset is selected when you make the

modiﬁcation, the change remains in effect until you switch

to a different preset. Since the modiﬁcation can’t be saved

with the factory preset (factory presets can’t be modiﬁed),

ClockWorks presents you with a window asking you if you

would like to save the current state of the interface as one

of the eight user presets:

Figure 6-43: Saving the current state of your Express interface to one of the

eight user presets.

Select one of the eight user presets from the pop-up menu,

type in a new name for it if you like, and click OK. The

modiﬁed factory preset gets saved as a user preset.

User Preset 3 03

User Preset 4 04

User Preset 5 05

User Preset 6 06

User Preset 7 07

User Preset 8 08
