CLOCKWORKS FOR MAC OS X
31
Familiarity with the Mac OS
In explaining how to use ClockWorks, this chapter
assumes that you are already familiar with the standard
Mac OS interface conventions, such as how to select
options using menus, check boxes, radio buttons, etc. and
how to type and edit text, and so forth.
Opening ClockWorks
When you first launch ClockWorks, the default view for
ClockWorks is the MIDI Routing window, which displays
the current MIDI processing configuration. (See Figure
5-1 on page 30.)
If your MOTU interface doesn’t appear
If your MOTU interface doesn’t show up in the Device
List, check the following things:
■
Your MOTU interface is turned off. Power it up and
choose
Refresh Device
from the ClockWorks File menu.
■
A MOTU interface is not connected to the computer, or
it is connected improperly. Make sure your cable
connection(s) to the interface match Figure 2-1 and
Figure 2-2 on page 9.
■
Open Audio MIDI Setup and make sure that the
interface is present in your current studio setup. If not,
scan for it as explained in “Launching Audio MIDI Setup”
on page 18.
■
If you make any adjustments to your hardware, choose
Refresh Device
from the ClockWorks File menu.
THE FILE MENU
Here is a brief explanation of each item in the ClockWorks
File menu.
Device List
The Device List menu item opens the Device List window.
See “the Device list” on page 32 for details.
Load Configuration
The
Load Configuration
menu item opens a previously
saved ClockWorks document and restores all of the
MOTU interface settings saved in the document.
