CLOCKWORKS FOR MAC OS X

Muting and remapping

On the MIDI IN ports, muting occurs before channel

remapping. On the MIDI OUT ports, channel remapping

occurs before muting, as shown in Figure 5-6.

For example, let’s say that on one of the MIDI ports, you

are muting channels 1-8, and you are also remapping all

channels (1-16) to channel 16.

If you did this on a MIDI IN port, channels 1-8 would get

muted, and the data on channels 9-16 would get mapped

to channel 16. If you did this on a MIDI OUT port, all data

on all channels would be sent out on channel 16, since all

channels are mapped to channel 16 before the muting

occurs on channels 1-8.

Here’s another example: Let’s say you are mapping all

channels to channel 1, and you are muting channels 1-8.

On input, only channels 9-16 will get rechannelized to

channel 1, because channels 1-8 get muted ﬁrst. On

output, no data would be sent because all channels are

mapped to channel one ﬁrst, and then channel 1 is muted.

Figure 5-6: How muting and remapping interact with each other.

MOTU interface data bus

Muting ﬁlter

Channel mapping ﬁlter

Muting ﬁlter

Channel mapping ﬁlter

MDI IN

MDI OUT
