Multi Edit Mode
OVERVIEW Page
9-7
Key Range
e Key Range is made up of two parameters that dene the region of the keyboard the
Zone is allocated to. e value to the left aects the lowest key, the value to the right the
upper key. e keyboard graphic in the Overview page clearly illustrates the Zone’s current
region
e lowest key determines the lower boundary of the currently selected Zone. You can set
this parameter to any note from C-1 to G9. If, for example, you set the lowest key to C4,
then only keys at or above C4 will trigger a note for the currently selected Zone. Keys below
C4 will not trigger a note.
e highest key parameter determines the higher boundary of the currently selected Zone.
You can set this parameter to any note from C-1 to G9. If, for example, you set the highest
key to C4, then only keys at or below C4 will trigger a note for the currently selected Zone.
Keys above C4 will not trigger a note.
You can also set the lowest key higher then the highest key and vice versa. is allows you to
split a Zone into two areas where the lowest and highest keys now dene the region that the
Zone does not play on.
Pan
e Pan parameter determines the Pan MIDI message that the currently selected Zone sends
when the Multi is loaded. You can set this parameter to any pan setting from None, 0 (full
left pan) to 127 (full right pan). To pan to center, select 64 for this parameter.
None can be entered as -1 on the keypad.
Volume
e Volume parameter determines the Volume MIDI message that the currently selected
Zone sends when the Multi is loaded. You can set this parameter to any volume setting from
None, 0 to 127.
None can be entered as -1 on the keypad.
