Multi Edit Mode
CONTROLS Page
9-21
Parameter Range Of Values Default Value
Controller See Controller List -
Mode Off, MIDI CC -
Destination See Multi Destination Control List -
Scale -300% to +300% 100%
Add -128 to 127 0
Curve
Linear, Compress, Expand, Cross-
fade, Bump, Rvrs Linear, Rvrs
Expand, Rvrs Compress, Rvrs
Crossfade
Linear
Entry Position None, 0 to 127 -
Exit Value None, 0 to 127 -
Controller
e Controller parameter allows you to assign any of the Forte’s physical controllers (sliders,
switches, mod and pitch wheels, foot switches and expression pedals) to control a program
specic parameter or MIDI controller number for the currently selected zone.
First, use the Channel /Zone buttons to the left of the display to select the desired zone that
you wish to assign a controller for. Next, on the CONTROLS page, use the cursor buttons
to select the “Controller” eld, hold the Enter button on the alphanumeric pad and then
move any of the Forte’s physical controllers. is will select that controller and display its
available parameters. (You can also scroll through the list of controllers on the Control page
by selecting the Controller eld with the cursor buttons and using the Alpha Wheel or the
Value buttons to scroll through the list.) If a pedal is selected which has a pedal override
enabled in Global mode, a message “Global Pedal Override is enabled” will display when that
pedal is viewed to remind you that the Global mode pedal override settings are being used
instead of the Multi mode pedal settings.
FORTE CONTINUOUS
CONTROLLERS
Mod Wheel Slider A
PitchUp Slider B
PitchDown Slider C
CC Pedal 1 Slider D
CC Pedal 2 Slider E
Pressure Slider F
Slider G
Slider H
Slider I
Select a Continuous controller from the list above, the Continuous controller parameters are
described below.
