MIDI Implementation
A-1
Appendix A
MIDI Implementation
Function Transmitted Recognized Remarks
Basic Channel
Default 1 1
Memorized
Changed 1–16 1–16
Mode
Default Mode 3 Mode 3
Use Multi-track mode (see FX Mode
(Global Mode) on page page 10-4
for multi-timbral applications)
Messages
Altered
Note Number
0–127
True Voice 0–127 0–127
Velocity
Note ON O O
Note OFF O O
Aftertouch
Keys X O
Channels O O
Pitch Bender O O
Control Change
O 0–31
32–63 (LSB)
64–127
O 0–31
32–63 (LSB)
64–127
Controller assignments are
programmable
Program Change
0 to 2,097,151 0–511
Standard and custom formats
True # 0–127 0–127
System Exclusive O O
System Common
Song Pos. X X
Song Sel. X X
Tune X X
System Real Time
Clock O O
Messages O O
Aux Messages
Local Control O O
All Notes Off O O
Active Sense X X
Reset X X
Notes
Manufacturer’s ID = 07
Device ID: default = 0;
programmable 0–127
Mode 1: Omni On, Poly
Mode 3: Omni Off, Poly
Mode 2: Omni On, Mono
Mode 4: Omni Off, Mono
O = Yes
X = No
