Storage Mode
The LOAD Page
11-9
OPEN
Pressing the Open soft button will open the highlighted folder, or open
the highlighted Kurzweil fi le allowing you to select individual objects
PARENT
Selecting Parent will close an existing open folder.
FILL
Selecting FILL means you would like to keep the existing User
Programs or Multis. Forte will now load the User Programs/Multis into
the fi rst empty ID slot it fi nds, and then subsequent empty slots
.
OVERWRITE
( OVWRTE)
Selecting OVWRTE fi rst deletes all the existing User Programs or
Multis, and then loads the new User Programs or Multis into the fi rst
user location at ID number 1024 onwards.
During the load process the screen will show information about the objects that are being
loaded. At the end, the screen will display a message indicating if the load process was
successful, or if there were errors.
Example Using LOAD
e following example shows how each dierent loading methods aect how four programs
load into the User bank that already contains programs.
Example: Starting with the following objects already stored in the Forte User bank:
Programs currently in Forte
Program ID Program Name
1024 3rd World Order
1025 PC3 Strings
1028 JuPiTaR BazZ
1031 VA1 Lead
Suppose you were to load a FOR (Forte) le containing the following Programs:
File to be Loaded
Program ID Program Name
1025 Synth Horn
1026 NYJazzy
1027 Saxxy
1028 Stabbatha
