Features of the Forte and Forte7
3-8
Master EQ & Compressor
Master EQ
e Master EQ allows you to have realtime control over the frequency response of all audio
generated in either Program or Multi Modes. When the Master EQ On/O button is “On”,
the rotary knobs can change the high, middle and low frequencies of the audio.
If the LED on the Master EQ On/O button is lit, this indicates that the Master EQ section
is now “on”.
e HI and LOW EQ’s are shelving type lters, and the MID has an adjustable center
frequency with a range of approximately 2 octaves up and down centered around
approximately 1.4 kHz
Frequency Gain
HI
~6.6 kHz -24dB to +15dB
MID*
~1.4 kHz -24dB to +15dB
LOW
98 Hz -24dB to +15dB
* center of range
Compressor
Use the Master Compressor to add compression to all audio generated in either Program
or Multi Modes. Press the Compressor On/O switch to enable the master compressor.
If the LED on the Master Compressor On/O button is lit, this indicates that the Master
Compressor is now “on”. Turn the Compressor knob to adjust the amount of compression
(left is minimum, right is maximum).
Generally, a compressor listens to an audio input signal and outputs a continuously volume
adjusted version of the input signal. A small amount of compression can help a sound to
blend with a band or other instruments by making the volume of each note more consistent.
Large amounts of compression act more like a special eect, reducing the attack volume of
notes, and increasing the decay, sustain and release volume of notes.
