Troubleshooting
Common Problems
13-3
ISSUE The volume slider is turned down.
REMEDY Slowly push the volume slider up.
ISSUE
The volume control on the audio system or mixer is turned
down.
REMEDY Slowly turn the volume control up.
ISSUE
The signal source selection on the audio system or mixer is
incorrect.
REMEDY
Set the volume of the audio or mixer to the lowest level, select
the correct signal source, and then slowly turn up the volume.
ISSUE
The audio cables are not securely plugged into the Forte,
audio system, or mixer.
REMEDY
Set the volume of the audio or mixer to the lowest level, securely
plug in the audio cables on both ends, and then slowly turn up
the volume.
ISSUE The Destination parameter stops MIDI Data.
REMEDY
Change the Global Mode (MIDI page) “Destination” parameter
to USB+MIDI+LOCAL (see page 10-13)
ISSUE The audio cable is of an incorrect type.
REMEDY
Obtain and securely connect an audio cable of the correct type.
The Forte accepts both balanced (TRS) and unbalanced (TS)
1/4-inch audio cables.
