NORD MODULAR V3.0 3. Getting started
Page 9
sizers are supported by the Editor. If you use several Nord Modular synthesizers, repeat the procedure for
the following Ports.
If the Nord Modular synth is not turned on, or if the connection between Nord Modular and the com-
puter is not working properly, an error message will appear. In that case, check the MIDI connections
and cables, make sure that the MIDI interface is properly installed and working, and that Nord Modular
is turned on. Click on the Apply button. When the Editor has found the Nord Modular synth, the Name
of the connected synth is shown in the Status line.
When you’re satisfied with the port selection, click OK. The port selection is automatically saved in the
Editor, so the next time you start the Editor, you don’t have to redo the selection. If ‘Auto Upload’ is
activated, which is the default setting in the Editor, the patch of the active
S
LOT
will automatically upload
and open in the patch window.
Note! Each time you start the Editor and establish contact with the Nord Modular, information about
all patches stored in the internal memory of the synthesizer will be sent from the synthesizer to the
Editor. This will take a couple of seconds depending on how many patches are stored in the synthesiz-
er. During this information transmission, the regular communication between the synthesizer and Ed-
itor will be slower.
H
HH
H
E
EE
EL
LL
LP
PP
P
F
FF
FI
II
IL
LL
LE
EE
ES
SS
S
I
II
IN
NN
N
T
TT
TH
HH
HE
EE
E
PC
PC PC
PC
V
VV
VE
EE
ER
RR
RS
SS
SI
II
IO
OO
ON
NN
N
O
OO
OF
FF
F
T
TT
TH
HH
HE
EE
E
E
E E
E
D
DD
DI
II
IT
TT
TO
OO
OR
RR
R
The PC version of the Editor comes with an extensive help section. To access the Help files, select Con-
tents from the Help menu. Every module and module parameter has its own pointer to the Help file. The
Help files can be accessed with the F1 key or by right-clicking on a module or parameter and selecting
Help. Note that Help files are only available in the Windows version of the Editor.
