NORD MODULAR V3.0 5. Panel reference
Page 53
G
GG
G
L
LL
LO
OO
OB
BB
BA
AA
AL
LL
L
S
SS
S
Y
YY
YN
NN
NC
CC
C
The MIDI Clock transmits 24 pulses per quarter note. The clock pulses can be divided with this function
and be sent as logic signals at the Sync output of the MIDI Global module (see picture above). These
logic signals can be used to synchronize the internal sequencer modules to an external MIDI sequencer.
A setting of “4 QUARTER NOTES” will result in one logic Sync pulse for every 96 pulses from the
Clock, which is equal to one pulse for every fourth quarter note.
This logic pulse can be used for resetting the sequencer modules in Nord Modular to the “first beat in
the bar”. If you do not use this function, the sequencer modules have no chance of knowing where they
are in a bar. With the Global Sync function activated, it will never take longer than the set number of
quarter notes for the sequencer modules to realign themselves, if you decide to start a MIDI sequence in
the middle of a song.
If you are synchronizing Nord Modular to an external MIDI Clock source, this function will keep track
of any incoming MIDI Song Position Pointer messages.
L
LL
L
O
OO
OC
CC
CA
AA
AL
LL
L
Turn the MIDI Local Control on or off.
Select Local On to be able to control Nord Modular from the internal keyboard and the pedals. MIDI
data is also transmitted via the
MIDI O
UT
jack.
In the Local Off mode, the keyboard and pedal actions are transmitted only via MIDI and do not control
Nord Modular itself. Local Off should be used with external sequencers as the
MIDI O
UT
jack of Nord
Modular is routed back, via the external sequencer, to the
MIDI I
N
jack. If Echo is active in the sequenc-
er, double notes will appear when playing the keyboard in Local On mode.
GLOBAL SYNC S
4 QUARTER NOTES
LOCAL S
ON
