5. Panel reference NORD MODULAR V3.0
Page 48
patch) and assign that parameter to the MIDI Controller you wish to transmit. Read more in “MIDI con-
trollers” on page 39.
S
SS
S
L
LL
LO
OO
OT
TT
T
B
BB
BU
UU
UT
TT
TT
TT
TO
OO
ON
NN
NS
SS
S
Pressing the
S
LOT
BUTTONS
A
,
B
,
C
and/or
D
selects the slots for loading, editing or playing. A patch
always has to be loaded into a slot before it can be used. If you select only one slot at a time, the
S
LOT
LED
will indicate this by a flashing green light. The Editor software will follow the slot selection (change
patch window), provided that the patch is uploaded or opened in the Editor.
If several slots are selected, by simultaneously pressing several
S
LOT
buttons, a solid green LED will in-
dicate a selected slot and a flashing LED will indicate the currently active
S
LOT
. Every selected
S
LOT
will
receive MIDI messages on their set channels, but only the active
S
LOT
will transmit MIDI messages.
To deselect
S
LOTS
in a multi-slot setup, press
S
HIFT
and the
S
LOT
(
S
)
you want to deselect. To deselect
all
S
LOTS
simultaneously, you can also press an unused
S
LOT
button (if there are any). However, the un-
used Slot will become active.
It is also possible to play several Slots simultaneously (layered) from the keyboard. To do that you must
first change keyboard mode to “Selected Slots” in “Keyboard mode” of the Synth Settings menu. See
“Keyboard mode” on page 54. On the Nord Modular rack model this function works only when playing
from the Keyboard Floater in the Editor. To play several
S
LOTS
layered on the rack model from a master
keyboard, the slots have to be set to the same MIDI channel.
S
SS
S
H
HH
HI
II
IF
FF
FT
TT
T
The
S
HIFT
button adds secondary functions to other buttons.
;;
;;
;;
;;
;;
;;
;;
;;
;
;
