You may mix different divisions of the clock pulses. The beauty of having 24 pulses for each quarter note
is that 24 is divisible with 3 and 4.
In this example, the clock is taken from the MIDI global module, at 24 pulses for each quarter note. It
is divided with the fixed divider module with two different division ratios, 16 and T8. The divider mod-
ule is reset by the logic signal from the Sync output on the MIDI global module. This reset signal is also
used on the two sequencer modules. The Global Sync function which is found in the Synth Setting menu
determines the rate of the pulse at the Sync output.
The upper module is set to a 16th note performance with 16 as the Last step. It receives the clock pulse
from the “16” output of the Clock Divider module, which in this example divides the System Clock to
4 pulses for every quarter note. The lower module is set to a 8 note triplet performance. The Last step is
set to 12 and it receives its clock from the T8 output, 3 pulses for each quarter note. The lower module
will sequence 12 steps during the same time as the upper module sequences 16.
The loop mode in both of the modules could be on or off, they will reset to step 1 when they receive the
Rst signal from the Sync output in any case.
By combining the settings of the loop mode, the Last step and the signals at the Rst inputs and the Snc
and Link outputs on various sequencer modules, you may assemble quite advanced sequencer perform-
ances.
