The unit will display the current Room
temperature.
4. And then by pressing the “ ” (1) button, the
unit will blow the cold air.
5. Upon pressing the “+” button, start set
the suitable temperature (the highest
temperature you can set until to 35°C), when
the setted temperature is higher then room
temperature, the unit will start one heat
setting, and at this time one of the “ ” will
light up. If continue pressing “+” the setted
temperature will be even higher. The unit will
start totally 2 heat settings.At this time the 2
“ ” will light up.
6. You can also press button “ ” (2) one or two
times to get heat directly. One time pressing
is in low heat setting, and two time pressing
is in high heat setting. When pressing this
button for third time, it will come back with
only cool air blowing mode.
7. By pressing “ ” (3), you can set the timer
from 0-8 hours.
8. By pressing “ ” (4), you can make the heater
with or without oscillation.
9. When you want to turn o the heater, you
can press “ ” (1), this time the symbol “fan
blade” will shining, and at the meaning time,
all the heating will turn o and only fan
blowing, after blowing 30s, the heater will
cut o only showing the room temperature.
OSCILLATION BUTTON
This appliance also have an oscillation function.
To switch the function on, press the “ ” (4)
switch. To stop it, press the swing switch again.
TIMER FUNCTION
This function will work in any mode.The timer
function allows you to set the length of opera-
tion from 1 hour to 8 hours.Pressing the Timer
button increase the length of operation by 1
hour each times the button is pressed.Once the
timer has been set the timer will count down
the hours in 1hour by 1 hour ,showing on the
display the remaining operating time until the
heater will turn itself o.Pressing the timer but-
ton once more after the display reects 8 hours
will reset the heater to continuously running.
THERMOSTAT INSTRUCTIONS
1. To adjust temperature, press the “+” to
increase the desired temperature and “ – “ to
decrease the desired temperature
2. When the air temperature reaches 3 degrees
above the set temperature, the heater will
cut o
3. When the air temperature drops 1 degree
below the set temperature, the unit will
come back on.
4. Temperature can setting from 15 degree to
35 degree
Remote control
1. Remote control, please use Lithium battery
CR2025 3 V.
2. The remote control power button is labeled
as such “ ”
3. All the functions perfomed with the remote
control work identically to the manual
controls.
SECURITY SYSTEM:
• The fan heater is equipped with overheating
shut-o which switchs, if the temperature
inside the appliance exceeds the normal
running temperature heating element
product will automatically stop working, the
motor will continue to operate, the internal
heat shed. This protective device applies only
to the appliance itself and has no inuence
on room temperature regulation.
• If overheating occurs, remove the plug
from socket, push buttons to switch the
convector o and let it cool down for at least
10 minutes. Put the plug in the socket and
switch the heater on.
• If you still notice the same defect above
mentioned remove the plug from socket and
have the convector serviced by authorized
service personal only.
MAINTENANCE:
• The fan heater only needs regular cleaning
on the outside.
• Before you clean the unit, turn the switch to
OFF. Remove the plug from socket and wait
until the fan heater cool down.
• Use a damp cloth to wipe the heater housing.
• Do not use water, detergents, abrasive
cleaning liquids or chemical agents (alcohol,
gasoline etc.) to clean the unit.
TECHNICAL CHARACTERISTICS
220-240 V • 50 Hz • 2000 W
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU. To
prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
3
ENGLISH
2
ENGLISH
INSTRUCTION MANUAL
This product is only suitable for well
insulated spaces or occasional use.
• Thank you very much for your purchase of
our Fan heater.
• Please read the instruction manual carefully
and keep it for future use.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electrical shock, burns
and other injury, including the following:
1. Study this instruction manual carefully
before using the product.
2. The device is only intended for private and
not for any commercial use.
3. Remove the unit from its packaging and
check to make sure it is in good condition
before using.
4. Do not let children play with parts of the
packing (such as plastic bags).
5. Check the household voltage to ensure it
matches the fan’s rated specication.
6. Check the power cord and plug carefully
before use to make sure that they are not
damaged.
7. Before unplugging the power cord, be sure
to turn o the power. When touching the
unit, be sure your hands are dry to prevent
from electric shock.
8. Do not use near or point the heater to
furniture, curtains or other inammable
objects. Keep back of fan heater min. 15 cm
away from walls or objects to allow free
airow.
9. Do not block air intakes or exhaust in any
manner to prevent a possible re.
10. Do not use or leave the fan heater
unattended when children, old or disabled
people are present.
11. Always unplug heater when not in use.
12. Prevent water from getting into the housing
of the heater during operation or in storage.
Hazard of electric shock. Always store in dry
area with no moisture.
13. Do not use in places where there are gas,
paint or other inammable goods and
objects
14. This heater is not intended for use in
bathrooms, laundry areas and similar indoor
locations. Never locate the heater where it
may fall into a bath tub or other bodies of
water.
15. Do not run the cord under carpeting. Do not
cover cord with throw rugs, runners or the
like. Arrange cord away from trac area and
where it will not be tripped over.
16. Do not use a soft surface, like a bed, where
openings may become blocked.
17. Use this heater only as described in this
manual. Any other uses not recommended
by the manufacturer may cause re, electric
shock, or injury to persons and may void
warranty.
18. Avoid the use of an extension cord because
the extension cord may overheat and cause a
risk of re.
19. Do not use outdoors.
20. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
21. Children should be supervised to ensure that
they do not play with the appliance.
22. This appliance heats up when in use. To
avoid burns, do not let bare skin touch hot
surfaces. Switch o and use handles where
provided when moving.
CAUTIONS
• This appliance is not a toy.
• This appliance is for household use only.
• Do not immerse the unit in the water.
• To avoid the risk of re or electric shock do
not remove the housing by yourself.
• Any servicing other than cleaning and user
maintenance should be performed by an
authorized service representative.
• If the supply cord is damaged, it must be
replaced by a special cord or assembly
available from the manufacturer or its service
agent.
• Repair should be done by an authorized
service personal only.
Warning: In order to avoid overheating,
DO NOT COVER the heater
Do not use this heater in the immediate
surroundings of a bath, a shower or a
Swimming pool.
OPERATION (see picture A)
1. Place the heater on a rm level surface
2. Setting the master button to “o”.plug the
cord set into a 220-240 V~AC electrical outlet.
Turnning the master button “on” position.
3. Turn the heater ON by pressing the ON/OFF
main button at the back side of the heater.
