Ака Berkut-5 VERSION 5.01 [11/43] Starting up the device



 A - a mode all metals

 D - the discrimination mode is enabled

 V – When discrimination mode is enabled will

indicate when Visual discrimination is on

Level of a charge of the battery;

T – Indicates AGB is enabled (at fine tuning carrying out

With some time it is replaced on R);

Index number of target VDI;

Level of a signal from object (a column on the right);

The menu of key parameters;

S - filter SFT is enabled;

K - the suppression filter of large objects is enabled;

M - the suppression filter of small objects is enabled;

An – Analog mode is enabled;

TURBO - the TURBO mode is enabled;

Indicates headphones installed.

Indication of value of current ground balance (-003)

STARTING UP THE DEVICE

Prior to turning on your detector please read the instructions thoroughly. Upon

every startup of the detector there is a calibration of the detector in air.

It is necessary for fine tuning of electronic parameters to the surrounding environment.

Therefore it is crucial to perform the following on every startup:

Hold the device firmly in your hand and if possible use the supplied armstrap to

steady the device

Lift the coil to waist level;

Be sure you are clear of any large metal objects within 6 feet;

Turn the power switch [ON].

Upon powering up on the display there will be information regarding the currently

installed coil, quantity of available calibrated coils, the version and date of the

software, and as the help on functions of buttons in the inclusion menu (a Fig. 8):

The gauge: D6x10-14 1

The version : 5.00

Date : 28.05.2012

[ПР]-RESET

[+]–COIL-SETUP

[Fn] – START MENU

Fig. 8
