Ака Berkut-5 VERSION 5.01 [15/43] A fn 180

М=002 БГ: +003

A Fn: +180

Fig. 15

In the right top part of the indicator the phase of balance of a ground is

represented in Degrees.

On top left – The level of ground mineralization in standard units.

On bottom left - Ground balancing mode (A - Automatic, Р -Manual).

4. Slowly and smoothly lower the coil to the ground avoiding touching grass,

stones, etc. Lower the coil at a speed of 1 to 2 seconds from the raised to

lowered position.

Upon lowering the coil to the ground, on the display, will appear a line in the

screen left-hand side (a Fig. 16). Lower the coil until the line reaches the display

left edge.

М=102 БГ: +005

AD Fn: +180

Fig. 16

5. At successful balancing, the device will play a melody

6. Press the button [GB] for transition to standard search mode;

7. If ground balance was not successful raise the coil waste high and wait 2-3 seconds

( ground line will retract to a small circle in center of screen). Repeat steps 4-6.

To enter the manual ground balance mode press either the + or - buttons. This

will allow you to adjust the ground balance point achieved in the automatic ground

balance procedure. The automatic GB procedure will be turned off and parameter

SPEED AGB will now be set to OFF. To return to previously set Speed AGB values

either perform automatic ground balance procedure again or simply access Speed AGB
