2. Disconnect the coil from the connector on the rear of the control box.

3. Remove the coil from the lower rod.

4. Install new coil on the lower rod.

5. Connect coil connector to the socket on the rear of the control box.

6. Turn on the detector while holding the [Fn] button

7. Press the up/down keys to choose select coil.

8. Press [+] to select

9. Buttons up/down keys to choose the installed coil.

10. Press [+] to select

11.The detector will automatically restart and make adjustments to the currently

installed coil.

12. Perform ground balance procedure.

Note that when the device reboots it will automatically perform an air balance.

Therefore it is necessary to hold the coil at waist level and away from any metal objects

while selecting the coil from the menu. This I similar to the procedures described on

page 12.

The detector should only be used with coils that have been preprogrammed into the

devices memory. To make demanded options it is possible as independently by means of the

built in program of adjustment of the gauge, and having addressed in firm AKA service-

center.

When bundled with the device, the coils used with different frequencies and

there are no sensors with the same frequency, switching of profiles is carried out

automatically, without operator assistance. This is only possible if all

sensors are pre-configured to work specifically with your device.

BATTERIES

The detector is powered by 4 AA batteries. It is recommended to use alkaline type

batteries or batteries whose rating is not less than 2500 Mah.

The current charge level of the batteries is displayed in the top left corner of the

display. A completely filled in icon indicates a full charge while a completely empty

icon indicates a discharged set of batteries.

When the batteries are almost fully discharged, and there are only a few minutes

of operating time left, a warning message will appear (fig 34) and a warning melody will be

heard. If the device had been operating in TURBO mode (CC=2) the detector will

automatically switch of TURBO (CC=1) to extend operating time. When the batteries are

fully discharged the detector will enter Sleep Mode and further operations are not possible.

LOW BATTERIES!

Charge or

Replace the battery!

Fig. 34
