Ака Berkut-5 VERSION 5.01 [19/43] The audio menu

THE AUDIO MENU

Audio Pag1

Volume: 10

Equalizer:

Volume S.S.: 8

Keys sound: On

Border Fe: -15

Num. of tones: 91F

Fig. 19

Audio Pag2

Sound freq: 5

Length fe: Short

Overload vol: 8

Sm signal vol: 4

Thresh volume: 0

Fig. 20

Under the Audio Menu section are available the following parameters for adjustment:

VOLUME[0-10] Sets the overall audio level of the detector.

EQUALIZER Allows the user to set unique volume levels to 12 different VDI

groups. The audio level is adjustable from 0-17 for each group. When the level is set

to 0 there is no audio response while a setting of 17 is maximum audio response. To

enter the Equalizer adjustment mode press the button [+]. On the screen will

appear the Equalizer menu for adjustment (a Fig. 21):
