DISPLAY MENU

DISPLAY

Backlight lev: 5

Backlight: On

Visual disc: Off

Accumulation: Off

Screen scale: 3

Fig. 22

Under the Menu DISPLAY the following parameters are available:

BACKLIGHT LEVEL [1- 5] Allows the user to set the level of backlight illumination.

Backlight is always set to off upon startup. The user can turn backlight on by

accessing the menu or by setting the Fn hot key to turn on and off backlight.

Turning the backlight on decreases the operating time. The higher the backlight

level the greater the power consumption. Therefore whenever possible set the

backlight setting to off or as low as possible

BACKLIGHT [Off/On/Auto] Turns backlight on or off. In the Auto setting the

backlight will turn on if a target is detected or a button is depressed. It will turn off

after a short period of time if no target is detected. This will help save battery life

during use of the backlight.

VISUAL DISCRIMINATION [On/Off] Turns visual discrimination on/off. This is

conditional on whether discrimination is set to on D ( not all metal A). When

discrimination is set to on(D) and visual discrimination is set to on( D will now

change to a V) any target that has been rejected in the discrimination card will not

generate a tone nor will it display a VDI or hodograph.

With discrimination on and visual discrimination set to off any target rejected by

the discrimination card will not generate a tone however a VDI and Hodograph

display will be seen.

ACCUMULATION [Off/1- 9] Determines the quantity of signals that will be stored

on the screen before being deleted. The use of accumulation can help in identifying

targets that are spaced close to each other. The given parameter matters only at

included mode VDI.

SCREEN SCALE [1... 4] Allows the user to change the size ratio of the hodographs

displayed on the screen when in mode VDI( not Analog mode). The size of the

hodograph is dependent upon signal strength. Objects that are small and/or deep

will have a very small hodograph and may be difficult to see. Conversely if an

object is large and shallow the hodograph may not fit completely within the screen.

To increase the size of the hodographs from weaker targets use a lower value. To

decrease the sizes of the hodograph then raise the value.
