COIL CURRENT (CC) [1- 2] Sets the level of current supplied to the coil. At

A setting of 2 (TURBO) maximum current is applied to the coil. Maximum depth

ability is achieved however operating time is decreased due to increased battery

usage. At the minimum setting of 1 maximum battery time is achieved at the cost of

reduced depth.

The remark. If operating near sources of electrical interference or other detectors

it is advised to set CC to 2 (turbo) and reduce sensitivity in order to reduce these

affects. On the other hand it may be necessary to reduce CC to 1 in order to

minimize the interference on other devices close by.

RECOVERY SPEED (RS) [1- 9] defines speed of the automatic tuning under

ground conditions in the dynamic mode (This setting has no affect in the pinpoint

or static mode). Reducing the speed of auto will increase the depth of search.

However in areas of considerable ground mineralization, target ID reliability can

worsen. There can be false responses from the ground, and also separation of the

closely spaced targets worsens. Lower settings of the recovery speed are

recommended for areas with deep targets, areas with low mineralization and areas

with little metal trash. It is also important to use a slower steady sweep speed

avoiding erratic movements, jerking etc. as well as keeping the coil parallel to the

ground. Increase in recovery speed settings is recommended for areas with many

closely spaced targets where target separation is most important. It is not

recommended to set the RS below 5.

AUDIO THRESHOLD (AT) [0- 20] defines the minimum signal level required to

generate an audio response on a detected object. Reducing the Audio Threshold

setting increases the sensitivity to small and deep targets but also increases the risk

of false audio responses. The device will react to the smallest particles of metal as

well as possible ground mineral concentrations. To achieve maximum depth of

search set the Audio Threshold as low as possible without creating excessive false

responses from the ground. Increasing the Audio Threshold will improve the

comfort of search by reducing false ground responses but at the expense of

reducing depth sensitivity. Unless there is a special reason to do so, do not set

the level too high as a loss in response sensitivity to large nonferrous items can

occur.

GAIN (GN)[0- 20] Defines overall sensitivity of the metal detector. The higher the

Gain the deeper the ability of the detector as well as increased response from smaller

targets. To achieve maximum depth and target response set the gain as high as

possible while still maintaining a stable detector. In areas of excessive ground

minerals or areas with a lot of metal trash it will be necessary to reduce gain levels

to a lower level. It is not recommended to set the gain to the maximum level

especially in areas with mineralization as performance will decrease at these

excessive settings. In most cases a maximum setting of 16 is recommended to avoid

false responses.

IDENTIFICATION THRESHOLD (IT) [0- 20] Defines the minimum signal level

required to generate a target ID audio response as well as to display a VDI value. If

a target is detected but does not meet the minimum signal level an audio

response from the threshold will be heard but no VDI number will be displayed.

Lower values will increase the depth response for target ID but reliability as well
