Мешок
1. Разместите зев мешка полностью под выходным
дефлектором. См. рис. 3-8A.
2. Затяните кулису, чтобы мешок плотно охватил отверстие
выходного дефлектора. См. рис. 3-8B.
3. Зажмите оба конца кулисы и плотно затяните ее на
выходном дефлекторе, чтобы зафиксировать мешок на
месте. См. рис. 3-8C.
раЗдел 3. сборка И прИведенИе в рабочее состоянИе
9
SECTION 3 — ASSEMBLY & SET-UP
Set-Up
Gas and Oil Fill-Up
3FGFSUPUIFTFQBSBUFFOHJOFPXOFSTNBOVBMGPSBEEJUJPOBM
engine information.
1. Add oil provided before starting unit for the first time out
of the box.
2. Service the engine with gasoline as instructed in the
TFQBSBUFFOHJOFPXOFSTNBOVBM
WARNING: Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
WARNING: Never fill fuel tank indoors with engine
running or until the engine has been allowed to cool
for at least two minutes after running.
Bag
1. Place the opening of the bag completely over the chute
deflector. See Figure 3-8A.
2. Pull on the drawstring until the bag is tight around chute
EFGMFDUPSPQFOJOH4FF'JHVSF#
3. Clip drawstring back on itself, tight against chute deflector
to secure into position. See Figure 3-8C.
A
B
C
Figure 3-8
9SECTION 3 — ASSEMBLY & SET-UP
Set-Up
Gas and Oil Fill-Up
3FGFSUPUIFTFQBSBUFFOHJOFPXOFSTNBOVBMGPSBEEJUJPOBM
engine information.
1. Add oil provided before starting unit for the first time out
of the box.
2. Service the engine with gasoline as instructed in the
TFQBSBUFFOHJOFPXOFSTNBOVBM
WARNING:
Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
WARNING: Never fill fuel tank indoors with engine
running or until the engine has been allowed to cool
for at least two minutes after running.
Bag
1. Place the opening of the bag completely over the chute
deflector. See Figure 3-8A.
2. Pull on the drawstring until the bag is tight around chute
EFGMFDUPSPQFOJOH4FF'JHVSF#
3. Clip drawstring back on itself, tight against chute deflector
to secure into position. See Figure 3-8C.
A
B
C
Figure 3-8
Рис. 3-8
Подготовка к работе
Заправка бензином и маслом
Дополнительная информация приводится в инструкции по
эксплуатации двигателя.
1. Перед первым запуском двигателя заправьте моторное
масло из входящей в комплект бутылки.
2. Заправьте двигатель топливом в соответствии
с указаниями инструкции.
ПРЕДУПРЕЖДЕНИЕ! Соблюдайте предельную
осторожность при обращении с бензином. Бензин
— легковоспламеняющееся вещество, и его пары
взрывоопасны. Никогда не заправляйте устрой-
ство в помещении, во время работы двигателя
или при горячем двигателе. Во время заправки
погасите сигареты, сигары, трубки и другие ис-
точники воспламенения.
ПРЕДУПРЕЖДЕНИЕ! Запрещается заправлять
топливо в бак в помещении при работающем
двигателе или не охладив его в течение двух
минут после работы.
5SECTION 2 — IMPORTANT SAFE OPERATION PRACTICES
3. #FGPSFDMFBOJOHSFQBJSJOHPSJOTQFDUJOHTUPQUIFFOHJOF
and make certain the impeller and all moving parts have
stopped. Disconnect the spark plug wire and ground it
against the engine to prevent unintended starting.
4. Do not change the engine governor settings or overspeed
the engine. The governor controls the maximum safe
operating speed of the engine.
5. Maintain or replace safety and instruction labels, as
necessary.
 Follow this manual for safe loading, unloading,
transporting, and storage of this machine.
 Never store the machine or fuel container inside where
there is an open flame, spark or pilot light such as a water
heater, furnace, clothes dryer, etc.
8. Allow machine to cool at least 5 minutes before storing.
9. "MXBZTSFGFSUPUIFPQFSBUPSTNBOVBMGPSQSPQFS
instructions on off-season storage.
10. If the fuel tank has to be drained, do this outdoors.
11. 0CTFSWFQSPQFSEJTQPTBMMBXTBOESFHVMBUJPOTGPSHBTPJM
etc. to protect the environment.
12. According to the Consumer Products Safety Commission
(CPSC) and the U.S. Environmental Protection Agency (EPA),
this product has an Average Useful LifePGTFWFOZFBST
PSIPVSTPGPQFSBUJPO"UUIFFOEPGUIFAverage Useful
Life have the machine inspected annually by an authorized
service dealer to ensure that all mechanical and safety
systems are working properly and not worn excessively.
Failure to do so can result in accidents, injuries or death.
Do not modify engine
To avoid serious injury or death, do not modify engine in any
way. Tampering with the governor setting can lead to a runaway
engine and cause it to operate at unsafe speeds. Never tamper
with factory setting of engine governor.
Notice Regarding Emissions
Engines which are certified to comply with California and federal
&1"FNJTTJPOSFHVMBUJPOTGPS403&4NBMM0GG3PBE&RVJQNFOU
are certified to operate on regular unleaded gasoline, and
may include the following emission control systems: Engine
.PEJGJDBUJPO&.0YJEJ[JOH$BUBMZTU0$4FDPOEBSZ"JS
Injection (SAI) and Three Way Catalyst (TWC) if so equipped.
Spark Arrestor
WARNING: This machine is equipped with an
internal combustion engine and should not be used
on or near any unimproved forest-covered,
brushcovered or grass-covered land unless the
FOHJOFTFYIBVTUTZTUFNJTFRVJQQFEXJUIBTQBSL
arrestor meeting applicable local or state laws (if
any).
If a spark arrestor is used, it should be maintained in effective
working order by the operator. In the State of California the
above is required by law (Section 4442 of the California Public
3FTPVSDFT$PEF0UIFSTUBUFTNBZIBWFTJNJMBSMBXT'FEFSBMMBXT
apply on federal lands.
A spark arrestor for the muffler is available through your
nearest engine authorized service dealer or contact the service
EFQBSUNFOU10#PY$MFWFMBOE0IJP
5SECTION 2 — IMPORTANT SAFE OPERATION PRACTICES
3. #FGPSFDMFBOJOHSFQBJSJOHPSJOTQFDUJOHTUPQUIFFOHJOF
and make certain the impeller and all moving parts have
stopped. Disconnect the spark plug wire and ground it
against the engine to prevent unintended starting.
4. Do not change the engine governor settings or overspeed
the engine. The governor controls the maximum safe
operating speed of the engine.
5. Maintain or replace safety and instruction labels, as
necessary.
 Follow this manual for safe loading, unloading,
transporting, and storage of this machine.
 Never store the machine or fuel container inside where
there is an open flame, spark or pilot light such as a water
heater, furnace, clothes dryer, etc.
8. Allow machine to cool at least 5 minutes before storing.
9. "MXBZTSFGFSUPUIFPQFSBUPSTNBOVBMGPSQSPQFS
instructions on off-season storage.
10. If the fuel tank has to be drained, do this outdoors.
11. 0CTFSWFQSPQFSEJTQPTBMMBXTBOESFHVMBUJPOTGPSHBTPJM
etc. to protect the environment.
12. According to the Consumer Products Safety Commission
(CPSC) and the U.S. Environmental Protection Agency (EPA),
this product has an Average Useful LifePGTFWFOZFBST
PSIPVSTPGPQFSBUJPO"UUIFFOEPGUIFAverage Useful
Life have the machine inspected annually by an authorized
service dealer to ensure that all mechanical and safety
systems are working properly and not worn excessively.
Failure to do so can result in accidents, injuries or death.
Do not modify engine
To avoid serious injury or death, do not modify engine in any
way. Tampering with the governor setting can lead to a runaway
engine and cause it to operate at unsafe speeds. Never tamper
with factory setting of engine governor.
Notice Regarding Emissions
Engines which are certified to comply with California and federal
&1"FNJTTJPOSFHVMBUJPOTGPS403&4NBMM0GG3PBE&RVJQNFOU
are certified to operate on regular unleaded gasoline, and
may include the following emission control systems: Engine
.PEJGJDBUJPO&.0YJEJ[JOH$BUBMZTU0$4FDPOEBSZ"JS
Injection (SAI) and Three Way Catalyst (TWC) if so equipped.
Spark Arrestor
WARNING: This machine is equipped with an
internal combustion engine and should not be used
on or near any unimproved forest-covered,
brushcovered or grass-covered land unless the
FOHJOFTFYIBVTUTZTUFNJTFRVJQQFEXJUIBTQBSL
arrestor meeting applicable local or state laws (if
any).
If a spark arrestor is used, it should be maintained in effective
working order by the operator. In the State of California the
above is required by law (Section 4442 of the California Public
3FTPVSDFT$PEF0UIFSTUBUFTNBZIBWFTJNJMBSMBXT'FEFSBMMBXT
apply on federal lands.
A spark arrestor for the muffler is available through your
nearest engine authorized service dealer or contact the service
EFQBSUNFOU10#PY$MFWFMBOE0IJP
