Stiga GRANNGÄRDEN MULCH 50 [27/104] En standards of use

STANDARDS OF USE

For instructions regarding the engine and the battery (if

supplied), read the relevant manuals.

NOTE - The number which precedes each paragraph links

the references in the text to the respective figures (listed on

the pages 2 - 3).

NOTE - The machine can be supplied with some parts al-

ready assembled.

WARNING - Unpacking and completing the assembly

should be done on a flat and stable surface, with enough

space for machine handling and its packaging, always

making use of suitable equipment.

Disposal of the packaging should be done in accordance

with the local regulations in force.

Return the lower part of the pre-fitted handle (1) to its

working position and lock into place using the lower knobs

(2). Attach the upper part (3) using the screws (4) supplied,

ensuring that the spiral (5) of the starter cable is in the cor-

rect position. Attach the control cables using the clips (6).

On models with an electric starter, connect the bat-

tery cable to the lawnmower’s general cable connection.

The throttle (where fitted) is controlled by the lever (1)

and positioned as shown on the relative plate.

Some models have a fixed speed, and therefore no need of

a throttle (2).

The blade brake is controlled by the lever (1), which

should be held against the handle when starting and using

the lawnmower. The engine stops when the lever is released.

In power-driven models, draw the lever (1) towards

the handle for forward movement. The lawnmower stops

moving forward when the lever is released.

The cutting height is adjusted using the levers (1).

The four wheels must be at the same height.

MAKE THIS ADJUSTMENT ONLY WHEN THE BLADE HAS

STOPPED MOVING.

To start, follow the instructions in the engine manual,

pull the blade brake lever (1) against the handle and firmly

pull the starter cable knob (2).

If the model has electric ignition pull the blade brake lever (1)

against the handle and turn the starter key (3).

The lawn will look better if it is always cut to the same

height and in alternate directions.

A machine with the MULCHING system cuts the grass,

chops it finely and then blows it down into the lawn.

The grass clippings need not be collected.

3.2

3.1

3. GRASS CUTTING

2.4

2.3

2.2

2.1

2. DESCRIPTION OF CONTROLS

1.2

1.1

1. COMPLETE ASSEMBLY

The following rules should be observed to give the best

MULCHING effect:

1. Use a high engine speed (full throttle).

2. Do not mow when the grass is wet.

3. Do not cut the grass too short. Not more than 1/3rd of the

length should be cut off.

4. Ensure that the area under the mower casing is always

kept clean.

5. Always use a well-sharpened blade.

LAWN CARE RECOMENDATIONS

Each type of grass has different features and may thus

require different ways to care for the lawn; always read the

instructions on seed boxes for mowing height for the growth

conditions in the work area.

Keep in mind that most grass is made up of a stem and one

or more leaves. If leaves are fully cut, the lawn is damaged

and growth is more difficult.

The following indications generally apply:

– too low a cut causes grass tears and uprooting, with a

“spotted” aspect;

– in the summer, cutting must be higher to avoid the ground

from drying;

– do not cut wet grass; this could reduce blade efficiency

due to sticky grass and tear the lawn;

– for particularly high grass, initially mow at maximum

admitted machine height followed by a second mow after

two or three days.

When you have finishing mowing, release the brake

lever (1) and disconnect the spark plug cap (2). Remove the

starter key (3) (where fitted). WAIT FOR THE BLADE TO

STOP before carrying out any type of work on the machine.

IMPORTANT – Regular, careful maintenance is essential

for keeping the safety level and original performance of

the machine unchanged in time.

Store the lawnmower in a dry place.

1) Wear strong working gloves during any cleaning, mainte-

nance or adjustment operation on the machine.

2) Carefully clean the machines with water after each cut;

remove the grass debris and mud accumulated inside the

chassis to avoid their drying and thus making the next

start-up difficult.

3) In models with painted chassis, internal chassis part

paint may detach over time due to the abrasive action of

cut grass; in this case, promptly touch-up paint with rust-

proof paint to prevent rusting that could corrode the

metal.

4) Should it be necessary to access the lower part, only tilt

the machine from the side shown in the engine handbook;

following the relative instructions.

5) Do not drip petrol onto the plastic parts of the motor or

the machine to prevent damaging them and remove all

traces of spilt petrol immediately. The warranty does not

cover damage to plastic parts caused by petrol.

6) In AVS models: in the event of abnormal handle vibra-

tions, check the vibration-proof sleeves and contact your

Dealer to replace them if damaged or worn.

Each intervention on the blade is best if conducted at

a specialised Centre that has the most appropriate tools.

4.1

4. ROUTINE MAINTENANCE

3.3
