Kawasaki VN1600 CLASSIC (2003) [168/575] 6 cooling system
![Kawasaki VN1600 CLASSIC (2003) [168/575] 6 cooling system](/views2/1121175/page168/bga8.png)
4-6 COOLING SYSTEM
Specifications
Coolant provided when shipping:
Type (recommended) Permanent type antifreeze (soft water and ethylene
glycol plus corrosion and rust inhibitor chemicals
for aluminum engines and radiators)
Color Green
Mixed ratio Soft water 50%, coolant 50%
Freezing point − 35°C (− 31°F)
Total amount
2.3 L (2.4 US qt., reserve tank full level including
radiator and engine)
Radiator Cap:
Relief pressure 93 ∼ 123 kPa (0.95 ∼ 1.25 kg/cm², 13.5 ∼ 17.8 psi)
Thermostat:
Valve opening temperature 58 ∼ 62°C (136 ∼ 144°F)
Valve full opening lift 8 mm (0.3 in) or more @ 75°C (167°F)
