PERIODIC MAINTE NANCE 2-9
Torque and Locking Agent
Torque
Fastener
N·m
kgf·m ft·lb
Remarks
Alternator outer cover assembly bolts 6.9 0.70 61 in·lb
Alternator cover bolts 11 1.1 95 in·lb
Alternator inner cover bolts 11 1.1 95 in·lb
Alternator rotor bolt 78 8.0 58 MO
Alternator stator bolts 13 1.3 113 in·lb L
Regulator/rectifier bolts 6.5 0.66 57 in·lb
Timing inspection cap 1.5 0.15 13 in·lb
Rotor bolt cap 1.5 0.15 13 in·lb
Starter motor terminal locknut 11 1.1 95 in·lb
Starter motor terminal nut 4.9 0.50 43 in·lb
Starter motor assembly bolts 4.9 0.50 43 in·lb
Starter motor mounting bolts
11 1.1 95 in·lb
Headlight rim screws 2.9 0.30 26 in·lb
Headlight unit bracket screws 1.0 0.10 8.7 in·lb L
Starter lockout switch screw 1.2 0.12 10 in·lb
Front brake light switch screw 1.2 0.12 10 in·lb
Sidestand switch bolt 8.8 0.90 78 in·lb L
Radiator fan switch
18 1.8 13
Radiator fan bolts
8.3 0.85 7.4 in·lb
Fuel level sensor mounting bolts 6.9 0.70 61 in·lb L
Fuel pump mounting bolts 9.8 1.0 87 in·lb S
Water temperature switch 7.8 0.80 69 in·lb SS
Water temperature sensor 18 1.8 13 SS
Oil pressure switch terminal screw 1.5 0.15 13 in·lb G
Oil pressure switch 15 1.5 11 SS
Neutral switch 15 1.5 11
Speed sensor mounting bolt 9.8 1.0 8.7 in·lb L
Turn signal light mounting screws 6.9 0.70 61 in·lb
Turn signal light lens screws 1.0 0.10 8.7 in·lb
Tail/brake light mounting nuts 5.9 0.60 52 in·lb
Tail/brake light lens screws 1.2 0.12 10 in·lb
Tail/brake light assembly screws 1.2 0.12 10 in·lb
