6-15
CHAS
FRONT BRAKE
2. Install:
8 Spring 1
Install the spring with its smaller diam-
eter to the master cylinder piston.
8 Master cylinder kit 2
3. Install:
8 Circlip 1
Install the circlip securely into the mas-
ter cylinder groove.
8 Master cylinder boot 2
YP.....
MASTER CYLINDER INSTALLATION
1. Install:
8 Master cylinder 1
8 Master cylinder bracket 2
9 Nm (0.9 m.kg, 6.5 ft.lb)
cC
8 Install the master cylinder bracket 2 with
the “UP” mark a facing upward.
8 Align the end of the holder with the punch
mark b on the handle bar.
New
T
R
.
.
New
START
ENG
INE STO
P
1
2
a
b
1
2
