SPEC
2-1
YW50AP
5PJ1
1,890 mm(74.4 in)
705 mm(27.8 in)
1,110 mm(43.7 in)
765 mm(30.1 in)
1,275 mm(50.2 in)
120 mm(4.7 in)
2,000 mm(78.7 in)
94 kg(207 lb)
Air cooled 2 strcke, gasoline torque induction
Forward- inclined single cylinder
49cm
3
(2.99 cu.in)
40.0 × 39.2 mm(1.57 × 1.54 in)
7.2:1
Electric and kick starter
Separate lubrication
For YAMAHA brand:
Yamalube 2 or Air cooled 2-stroke engine oil (ISO
EG-C, EG-D grade)
Yamalube 4 SAE 10W/30 SE or GL gear oil
1.4 L (1.23 lmp•qt, 1.48 US qt)
0.11 L(0.096 lmp.qt, 0.12 US qt)
0.13 L(0.11 lmp.qt, 0.13 US qt)
Wet type element
Regular unleaded gasoline
5.7 L (1.25 lmp.gal, 1.5 US gal)
Y14P/1/ TEIKEI
GENERAL SPECIFICATION
SPECIFICATION
GENERAL SPECIFICATION
Model
Model code:
Dimensions:
Overall length
Overall width
Overall height
Seat height
Wheelbase
Minimum ground clearance
Minimum turning radius
Basic weight:
With oil and full fuel tank
Engine:
Engine type
Cylinder arrangement
Displacement
Bore × stroke
Compression ratio
Starting system
Lubrication system:
Oil Type or Grade:
Engine Oil
Transmission Oil
Oil Capacity:
Oil Tank (Engine Oil)
Transmission Oil:
Periodic Oil Change
Total Amount
Air Filter:
Fuel:
Type
Tank Capacity
Carburetor:
Type / Manufacturer
