Konica Minolta bizhub 181 [132/340] Selecting the search method

Network settings

5-52 NC-503

Selecting the search method

1 In the "LDAP SETTING" menu, press the [+] or [,] key until "SEARCH

METHOD" is selected, and then press the [OK] key.

2 Press the [+] or [,] key until "BEGIN", "CONTAIN" or "END" is

selected, and then press the [OK] key.

– Whether "BEGIN", "CONTAIN" or "END" is selected, the message

"ACCEPTED" appears, and then the "LDAP SETTING" menu

appears again.

LDAP SETTING

ATTRIBUTE

SEARCH BASE

SEARCH METHOD

CONTAIN

BEGIN

END
