Konica Minolta bizhub 181 [247/340] When using pagescope web connection

Using PageScope Web Connection

NC-503 9-3

9 Using PageScope Web Connection

9.1 When using PageScope Web Connection

In order to use PageScope Web Connection, optional network interface card

NC-503 and image controller IC-206 must be installed.

9.2 About PageScope Web Connection

PageScope Web Connection is a device management utility integrated into

the printer controller for this machine. Using a Web browser, PageScope

Web Connection can be used as an interface to remotely control this

machine.

HTTP server

Access
