Performing a scan to e-mail operation
7-42 NC-503
7.8 Specifying a speed dial destination
1 Press the [Scan] key.
The machine enters Scan mode, and the Scan mode screen appears.
2 Press the [Speed Dial] key, and then use the keypad to type in the 3-
digit speed dial number (number programmed with the e-mail address).
3 Press the [OK] key.
– The destination is specified.
2
Note
The recipient must have been registered with a speed dial number in
advance.
For details on programming speed dial numbers, refer to "Registering
destinations" on page 6-3.
If the number was incorrectly entered, press the [Back] key, and then type
it in correctly.
300x300dpi TIFF 100%
SET DESTINATION
TEXT/PHOTO
300x300dpi TIFF 100%
SPEED DIAL:001
TEXT/PHOTO
-PRESS OK KEY-
