Konica Minolta bizhub 181 [198/340] Selecting the compression encoding method

Performing a scan to e-mail operation

7-22 NC-503

Selecting the compression encoding method

1 Press the [Scan] key.

The machine enters Scan mode, and the Scan mode screen appears.

2 Position the document, and then specify the recipient.

"OTHER SETTING=," appears.

3 Press the [,] key.

The "SCAN OTHER SETTING" menu appears.

300x300dpi TIFF 100%

SET DESTINATION

TEXT/PHOTO

300x300dpi TIFF 100%

TO:user@test.loc

TEXT/PHOTO

OTHER SETTING=
