Konica Minolta bizhub 181 [46/340] When using a windows operating system

Network printing

3-4 NC-503

When using a Windows operating system

Peer-to-peer printing

Compatible operating systems: Windows 98 SE/Windows Me

Peer-to-peer printing

- Using the Peer-to-Peer Utility, the computer and this machine are

connected over a network. Since there is no differentiation between client

and server computers, this method is appropriate for network

connections on a small-scale LAN. The Peer-to-Peer Utility is installed on

the computer when the printer driver is installed.

TCP/IP protocol

Computer

Network interface

card NC-503
