Konica Minolta EP6000 [173/193] Duplexing document feeder
![Konica Minolta EP6000 [173/193] Duplexing document feeder](/views2/1122172/page173/bgad.png)
Standard Mode: 1-sided original
2-sided original
2-in-1
Mixed Original Detection Mode:
1-sided mixed original detection
2-sided mixed original detection
Lightweight Original Mode
Name Duplexing Document Feeder AFR-9
Type Take-up from bottom of stack and U-turn feeding to Glass, loop turnover, U-turn
ejection
Installation On top of copier, with two Hinges at the back
Document Feeding Single Belt transport
Document Stop
Reference
Left side
Document Feeding
Registration
Rear edge
Document Feeding
System
Kinds of Original Plain paper
Original Weight
Original Size 1-sided/2-sided Original Mode:
1-A3L, B4L, A4L, A4C, A5L, A5C, FLSL
2-in-1 Mode: A4C, A5C
1-sided/2-sided Mixed Original Detection Mode:
1-A3L, B4L, A4L, A4C, FLSL
Capacity of Document
Feed Tray
A4L, A4C, B5L, B5C, A5L, A5C: 50 sheets (80 g/m
2
)
A3L, B4L: 30 sheets (80 g/m
2
)
Document Loading Face up
Copy Productivity 100%
First copy in automatic
document feeding
5.1 seconds or less
Power Source DC24V supplied from copier
Power Consumption 60W or less
Dimensions Width
Depth
Height
: 610 mm
: 505 mm
: 127 mm (Excluding Document Exit Tray)
Weight 14.4 kg
1-sided Original Mode, 2 in 1 Mode
2-sided Original Mode,
1-sided/2-sided Mixed Original
Detection Mode
Lightweight Original Mode
: 50 to 110 g/m
2
: 60 to 90 g/m
2
: 40 to 110 g/m
2
*60 to 110 g/m
2
for A5 size originals for all modes
2. Duplexing Document Feeder
Chapter 7
Specifications
160
