25.0.1.1 Packet Capture Command Example
The following examples show how to configure packet capture settings and perform a packet
capture. First you have to check whether a packet capture is running. This example shows no other
packet capture is running. Then you can also check the current packet capture settings.
Exit the sub-command mode and have the NWA/WAC capture packets according to the settings you
just configured.
Manually stop the running packet capturing.
Check current packet capture status and list all packet captures the NWA/WAC has performed.
You can use FTP to download a capture file. Open and study it using a packet analyzer tool (for
example, Ethereal or Wireshark).
Router(config)# show packet-capture status
capture status: off
Router(config)#
Router(config)# show packet-capture config
iface: lan
ip-version: any
proto-type: any
host-port: 0
host-ip: any
file-suffix: lan-packet-capture
snaplen: 1500
duration: 0
file-size: 1000
Router(packet-capture)# exit
Router(config)# packet-capture activate
Router(config)#
Router(config)# no packet-capture activate
Router(config)#
Router(config)# show packet-capture status
capture status: off
Router(config)# dir /packet_trace
File Name Size Modified Time
===========================================================================
lan-packet-capture.cap 575160 2009-11-24 09:06:59
Router(config)#
