Zyxel NWA5123-AC [18/144] List of available commands

Chapter 1 Command Line Interface

NWA/WAC Series CLI Reference Guide

1.6 Shortcuts and Help

1.6.1 List of Available Commands

A list of valid commands can be found by typing ? or [TAB] at the command prompt. To view a list of

available commands within a command group, enter <command> ? or <command> [TAB].

Figure 4 Help: Available Commands Example 1

Figure 5 Help: Available Command Example 2

Router> ?

<cr>

apply

atse

clear

configure

------------------[Snip]--------------------

shutdown

telnet

test

traceroute

wlan-report

write

Router>

Router> show ?

aaa

account

app-watch-dog

apply

arp-table

------------------[Snip]--------------------

wlan-security-profile

wlan-ssid-profile

wtp-logging

Router> show
