Chapter 1 Command Line Interface
NWA/WAC Series CLI Reference Guide
17
1.5 CLI Modes
You run CLI commands in one of several modes.
See Chapter 6 on page 41 for more information about the user types. User users can only log in,
look at (but not run) the available commands in User mode, and log out. Limited-Admin users
can look at the configuration in the web configurator and CLI, and they can run basic diagnostics in
the CLI. Admin users can configure the NWA/WAC in the web configurator or CLI.
At the time of writing, there is not much difference between User and Privilege mode for admin
users. This is reserved for future use.
Table 2 CLI Modes
USER PRIVILEGE CONFIGURATION SUB-COMMAND
What User users
can do
• Look at (but not
run) available
commands
Unable to access Unable to access Unable to access
What Limited-
Admin users can
do
• Look at system
information (like
Status screen)
• Run basic
diagnostics
• Look at system
information (like
Status screen)
• Run basic
diagnostics
Unable to access Unable to access
What Admin
users can do
• Look at system
information (like
Status screen)
• Run basic
diagnostics
• Look at system
information (like
Status screen)
• Run basic
diagnostics
• Configure simple
features (such as
an address
object)
• Create or remove
complex parts
(such as an
interface)
• Configure
complex parts
(such as an
interface) in the
NWA/WAC
How you enter it Log in to the NWA/
WAC
Type enable in User
mode
Type configure
terminal in User or
Privilege mode
Type the command
used to create the
specific part in
Configuration
mode
What the prompt
looks like
Router> Router# Router(config)# (varies by part)
Router(config-
if-brg)#
...
How you exit it Type exit Type disable Type exit Type exit
