Zyxel NWA5123-AC [14/144] Console port
![Zyxel NWA5123-AC [14/144] Console port](/views2/1169061/page14/bge.png)
Chapter 1 Command Line Interface
NWA/WAC Series CLI Reference Guide
14
1.2.1 Console Port
The default settings for the console port are as follows.
When you turn on your NWA/WAC, it performs several internal tests as well as line initialization.
You can view the initialization information using the console port.
• Garbled text displays if your terminal emulation program’s speed is set lower than the NWA/
WAC’s.
• No text displays if the speed is set higher than the NWA/WAC’s.
• If changing your terminal emulation program’s speed does not get anything to display, restart the
NWA/WAC.
• If restarting the NWA/WAC does not get anything to display, contact your local customer support.
Figure 1 Console Port Power-on Display
After the initialization, the login screen displays.
Figure 2 Login Screen
Enter the user name and password at the prompts.
Note: The default login username is admin and password is 1234. The username and
password are case-sensitive.
1.2.2 Telnet
Use the following steps to Telnet into your NWA/WAC.
1 If your computer is connected to the NWA/WAC over the Internet, skip to the next step. Make sure
your computer IP address and the NWA/WAC IP address are on the same subnet.
Table 1 Managing the NWA/WAC: Console Port
SETTING VALUE
Speed 115200 bps
Data Bits 8
Parity None
Stop Bit 1
Flow Control Off
FLASH: AMD 16M
BootModule Version: V1.13 | 06/25/2010 15:05:00
DRAM: Size = 256 Mbytes
DRAM POST: Testing: 262144K
Welcome to NWA3160-N
Username:
